Box Culverts
Box Culverts
Box Culverts are commonly used in either a crown configuration with a base or an inverted configuration with a lid.
- All our box culverts are designed and manufactured to the relevant Australian Standards and conform to VicRoads specifications.
- Shop drawings can be provided on request.
- Quick and easy to install, resulting in minimal disruption to services and traffic.
- Easy to unload and install on site, with cast in lifting points for ease of placement.
All items shown on this page are stocked items only. Other sizes are available - please ask one of our friendly staff for more information.
Lids, Link Pads, Base Slabs, & Headwalls
We manufacture all lids, link pads, base slabs, and headwalls to suit all sizes of box culverts, conforming to Australian Standards and VicRoads specifications.
Culvert Specifications
NOTE: You may need to scroll the table below left/right for more information
| Internal Width/Span (mm) |
Internal Min Height (mm) |
Internal Max Height (mm) |
Length (mm) |
| 300 |
150 |
600 |
1220 |
| 600 |
300 |
600 |
1220 |
| 900 |
300 |
1200 |
1220 |
| 1200 |
300 |
1200 |
1220 |
| 1500 |
300 |
1500 |
1220 |
| 1800 |
300 |
1800 |
1220 |
| 2100 |
300 |
2100 |
1220 |
| 2400 |
300 |
2400 |
1220 |
PRODUCT ENQUIRY
GET A QUICK QUOTE NOW!
DON’T SEE EXACTLY WHAT YOU NEED?
WE OFFER COMPLETE CUSTOM MADE OPTIONS!
Vikon are specialists in providing quality concrete products and can manufacture the right solution for you. Contact us to discuss how we can assist with your project.
